jcb JS260

60 - 1
Schematic
Section E
Hydraulics
9803/6400
Section E
60 - 1
Issue 3*
Stacked (Slew Brake) Valve
Solenoid Part Valve Part
1. Voltage DC24V 1. Working Pressure 3.9 MPa (40 kgf/cm
2
)
2. Consumed Power 12W 2. Working Flow 16 l/min
3. Other Surge Suppressor 3. Decompressor Pressure
JS200/240
Pressure 1.5
+0
MPa
(15
+0
kgf/cm
2
)
*
