77 - 6
Section E
Hydraulics
9803/6400
Section E
77 - 6
Issue 1
Hydraulic Rams
Reconditioning
(continued)
Bush removal
(continued)
With the chuck assembly (jig) and bushing removed, turn
the adjuster with your fingers until there is no gap between
the adjuster and the wedge upper surface.
Note:
Do not remove the adjuster and wedge from the
chuck assembly .
11. Retightening the adjuster
