1 - 1
Section J
Track and Running Gear
9803/6400
Section J
1 - 1
Issue 2*
Torque Specifications
Torque Specifications JS200/JS240
Component Nm kgfm lb/ft Remarks
Drive sprocket
fastening bolts 267-312 27.2-31.8 196.65-229.91 Apply 262
Idler wheel
installation bolts 267-312 27.2-31.8 196.65-229.91 Apply 262
Top roller
installation bolts 521-608 53.1-62 383.91-448.26 Apply 262
Bottom roller
installation bolts 371-432 37.8-44.1 273.29-318.84 Apply 262
Recoil unit
installation bolts 380-443 38.7-45.2 279.8-326.79 Apply 262
Track shoe bolt 775.1-931.6 77-95 556.71-686.85 Apply 262
Note: Install the drive sprocket with the chamfer to the body side.
*
*
*
*
