Routine Maintenance
Oiling
119 119
9811/5700-7
Oiling
The following points should be lightly oiled with engine oil.
!MWARNING
Make the machine safe before working underneath it.
Park the machine on level ground, lower the
attachments to the ground. Apply the park brake, put
the transmission in neutral and stop the engine. Block
both sides of all four wheels.
Disconnect the battery, to prevent the engine being
started while you are beneath the machine.
GEN-4-1_1
Park Brake Cable
!MWARNING
Oil on the brake disc will reduce brake effectiveness.
Keep oil away from the brake disc. Remove any oil
from the disc with a suitable solvent. Read and
understand the solvent manufacturer's safety
instructions. If the pads are oily, new ones must be
fitted.
2-3-2-3_3
Oil the clevis A and pivots at the brake end of the cable.
Fig 82.
Control Levers
Oil the clevis A of each hydraulic control lever. Remove the
gaiter retaining plate B and lift the lever gaiter C to gain
access to the clevises.
Fig 83.
