jcb RTFL 930 - Safety Equipment

Operation
Safety Equipment
48 48
9811/5700-7
Safety Equipment
Control Locks
The requirement for control lever lock/isolation varies
according to local legislation. You must comply with local
legislation at all times. The locks are designed to lock or
isolate the controls in the neutral position.
Lock the controls before you travel on public roads.
To lock the controls:
1 Make sure that the control levers A are in the neutral
position.
2 Lower the locking bars B into the horizontal position.
K
Fig 39. ( T 48).
3 Push the locking bars into clips C to secure the
control levers in the locked position.
4 Before you start the engine, make sure that the
controls are locked.
To release the controls:
1 Raise the locking bars into the vertical position.
K
Fig 40. ( T 48).
2 Push the locking bars into clips D to secure the
control levers in the locked position.
T011630-2
Fig 39. Controls Locked
T011630-3
Fig 40. Controls Unlocked
