Routine Maintenance
Brakes
124 124
9811/5700-7
Note: Do not do this test for longer than 20 seconds.
d Reduce engine speed to idle and select neutral.
e Return the park brake lever to the fully on position.
f Lower attachments and stop the engine.
8 If the machine moved during the test, adjust the park
brake and repeat the test. Refer to Park Brake
Adjustment.
Park Brake Adjustment
!MWARNING
Over adjustment of the park brake could result in the
park brake not fully releasing.
0011
1 Disengage the park brake (lever horizontal).
2 Turn handle grip A clockwise, half a turn.
3 Test the park brake.
4 If the brake fails the test, repeat steps 1, 2 and 3. If
there is no more adjustment and pin B is at the end of
its travel get the brake checked by your JCB dealer.
Fig 87.
B
