Routine Maintenance
Electrical System
127 127
9811/5700-7
5 Close and lock the access panels.
Battery Isolator (if fitted)
To disconnect the battery from the machine electrics a
battery isolator has been fitted.
!MCAUTION
Before carrying out arc welding on the machine,
disconnect the battery and alternator to protect the
circuits and components. The battery must still be
disconnected even if a battery isolator is fitted.
INT-3-1-13
At the end of a working cycle or if the machine is being left
unattended, provided the lights are not required, the
battery must be isolated. Before attempting to start the
engine or use the machine electrics the battery isolator key
must be fitted and switched on.
1 To isolate the battery turn the battery isolator key A in
an anti-clockwise direction B and remove. Keep the
key in a safe place and available for when the
machine is next required.
2 To connect the battery insert the key A and turn in a
clockwise direction C.
!MCAUTION
Before carrying out arc welding on the machine,
disconnect the battery and alternator to protect the
circuits and components. The battery must still be
disconnected even if a battery isolator is fitted.
INT-3-1-13
