jcb S2632E User Manual

Technical Data
Electrical System
98 9831/3200-3 98
Fuse Circuit Rating
3 Permanent feed - emergency stop, charger switch, ignition key, Up/Down
switch, platform controller
5A
4 Ignition feed - main ECU controller, hour meter feed, motor controller 7.5A
5 Ignition Feed - lower limit, Tilt switch, angle sensor, pressure sensor 1, pot-
hole switch 2 (right hand) separate input
5A
6 Lower limit switch input 2, upper limit switch, pressure sensor 2, left hand/
right hand pothole series connection
5A
7 Livelink ignition feed (option), ground alarm 5A
8 Spare -

jcb S2632E Specifications

General

Machine Width	0.81 m
Power Source	Electric
Drive Speed - Stowed	4.0 km/h
Drive Speed - Elevated	0.8 km/h
Gradeability	25%
Tyre Type	Non-marking
Power Source Voltage	24V
Machine Length	2.3 m
Machine Height	2.3 m
