jcb S2632E User Manual

Maintenance
Access Apertures
64 9831/3200-3 64
Figure 39.
A
B
C
A Lock B Handle
C Cover
Close
1. Close the cover.
2. Make sure the cover is secured correctly.
3. Use the key to lock the cover.

jcb S2632E Specifications

General

Machine Width	0.81 m
Power Source	Electric
Drive Speed - Stowed	4.0 km/h
Drive Speed - Elevated	0.8 km/h
Gradeability	25%
Tyre Type	Non-marking
Power Source Voltage	24V
Machine Length	2.3 m
Machine Height	2.3 m
