Technical Data
Static Dimensions
89 9831/3200-3 89
(For: S4046E)
Table 30.
Description Dimension
Overall weight 2,996kg
Load capacity 320kg
Maximum platform occupants (indoor) 2 persons
Maximum platform occupants (outdoor) 1 person
Maximum allowable side force (indoor) 400N
Maximum allowable side force (outdoor) 200N
Maximum wheel loads 1,180kg
(For: S4550E)
Table 31.
Description Dimension
Overall weight 3,366kg
Load capacity 227kg
Maximum platform occupants (indoor) 2 persons
Maximum platform occupants (outdoor) N/A
Maximum allowable side force (indoor) 400N
Maximum allowable side force (outdoor) N/A
Maximum wheel loads 1,140kg

jcb S2632E Specifications

General

Machine Width	0.81 m
Power Source	Electric
Drive Speed - Stowed	4.0 km/h
Drive Speed - Elevated	0.8 km/h
Gradeability	25%
Tyre Type	Non-marking
Power Source Voltage	24V
Machine Length	2.3 m
Machine Height	2.3 m
