PRINTER SENSOR FUNCTIONS
There are five (5) primary Sensor functions on the GEN5 Printer.
Bezel light and Keypad LEDs may indicate a Sensor-related error
condition (refer to Table 3).
Table 3 GEN5 Printer Sensor Status
Sensor Location/Description
Paper Out
Located in the Print Head, Paper Out indicates that paper is
not loaded in the GEN5 Printer.
Paper Low
Located in the Paper Tray, Paper Low indicates that less
than two (2) Tickets are detected in the GEN5 Printer.
Paper Taken
Located in the Presenter Chute, Paper Taken indicates that a
Ticket remains in the Presenter Chute.
Drawer Open
Located on the CPU Board, Drawer Open indicates that the
Printer is not seated properly in the Host Machine.
Printer Lid Open
Located in the Print Head, Printer Open indicates that the
Printer Lid is open.
