CONFIDENTIAL PROPERTY OF JCM GLOBAL DRAFT 5 © 2010, Japan CashMachine Co, Limited
iii
iVIZION™ Series
Integration Guide
List of Figures
Page
LOF
Figure 1 iVIZION Unit..................................................................................................1
Figure 2 iVIZION Component Names ...............................................
..........................2
Figure 3 Interface Harness Installation Location.........................................................4
Figure 4 M4 Screws Locations (Left/Right Side).........................................................4
Figure 5 Flat Head Screws Locations (Rear Side)
......................................................4
Figure 6
Cable Interconnection ...................................................................................5
Figure 7 iVIZION Sensor Cleaning Locations .............................................................
6
Figure 8 iVIZION Banknote Acceptor Unit Outside Dimensions .................................8
Figure 9 i
VIZION Installation and Maintenance Space Requirements Diagram .........9
Figure 10 Maximum Gradient Angle = 50 Degrees.......................................................9
Figure 11 iVIZION Standard Cash Box Outside Dimensions......................................10
Figure 12 iVIZION Large Cash Box Outside Dimensions ...........................................10
