JCM ivizion ss User Manual

P/N 960-100929R_Rev. 7 {EDP #148849} © 2017, JAPAN CASH MACHINE CO., LTD.
7-46
Section 7 iVIZION® Series Next-Generation Banknote Acceptor Unit Exploded Views & Parts Lists
iVIZION HC Pusher Assembly 2 Parts List
Table 7-25 iVIZION HC Pusher Assembly 2 Parts List
Ref No. EDP No. Description Qty Remark
2401 226073 Inside Guide L 1
2402 226074 Inside Guide R 1
2403 226077 Arm Pusher 1
2404 226094 Gear Stack B 2
2405 226095 Gear Stack C 2
2406 226084 Stacker Transport Shaft C 1
2407 226087 Stacker Stud Shaft B 1
2408 226088 Stacker Stud Shaft C 1
2409 226089 Stacker Stud Shaft D 1
2410 226090 Stacker Stud Shaft E 1
2411 226091 Stacker Stud 2
2412 226081 Stacker Arm Spring 1
2413 239381 Arm Pusher 1
2414 147959 Arm Left 1
2415 147960 Arm Right 1
2416 147961 Home Position Lever 1
2417 147926 Feed Drive Pulley 2
2418 147927 Feed Driven Pulley 2
2419 147928 Feed Idol Pulley 2
2420 147933 Feed Idol Roller 4
2421 185197 Arm Slide Roller 8
2422 147821 Feed Pulley Shaft 8
2423 147822 Arm Link Pin 1
2424 147765 Arm Spring 1
2425 148033 Timing Belt 2
2426 226096 Bearing 2
2427 003598 2.6x6 Washer 2
2428 063250
2.6x6 Self-tapping Binding Screw
*
*. P-TITE is recommended.
1
2429 056165
2.6x8 Self-tapping Binding Screw
*
2
2430 104027 2x8 Parallel Pin (Hard) 4
2431 064863 2x14 Parallel Pin (Hard) 1
2432 066091 3x14 Parallel Pin (Hard) 2
2433 061317 3x22 Parallel Pin (Hard) 1
2434 091516 φ3 E-Ring 2
2435 104036 φ4 E-Ring 2
