Adjusting MAG Gain
MAG GAIN ADJUST
<scr 11>
Write the adjustings to VALI HEAD. Yes-->Y No-->N :
<scr 12>
Complete
Push Enter KEY TO CONTINUE. END:ESC KEY.
DATE: xxxxxxxx ID: WBAxxxxxx
Write Complete
<scr 13>
(16) When the “MAG Center A/D” value enters the designated range, press the ENTER key. The
calibration starts and screen 11 appears.
(17) When the calibration is complete, screen 12 appears. A prompt asks if the calibration results should be
written in the acceptor head memory. Press the Y key and then ENTER to write the data to memory. If
you choose N, all the calibration data will be lost when the power turns off.
(18) When the screen 13 appears, all calibration procedures are complete. If you wish to continue calibration
with another acceptor head, press ENTER and replace with a new acceptor head. To end calibration
procedure, press ESC.
