Jconcepts BJ4 - Miscellaneous Components

4-40 x 3/8"
BUTTON HEAD
x 8
SERVO MOUNT
SPACERS
(PARTS TREE)
THICK x 2
THIN x 2
SERVO HORNS
AIRTRONICS
FUTABA
HI-TEC
JR
x 1 EA
AE BODY CLIP
x 2
LOSI BODY CLIP
x 5
4-40 x 1/4"
FLAT HEAD
x 2
SERVO MOUNTS
(PARTS TREE)
x 2
SHORT
BALL CUP
x 2
4-40 x 3/8"
SOCKET HEAD
x 2
GOLD WASHER
x 6
TITANIUM
TURNBUCKLE
(STEERING)
x 1
BATTERY
HOLD DOWN
x 1
STEERING TURNBUCKLE ASSEMBLY:
4-40 x 3/8"
SOCKET HEAD
x 1
REAR BODY
MOUNT
x 1
WING MOUNTS
x 2
WING MOUNT
SPACER
x 2
3mm x 10mm
SOCKET HEAD
x 2
SHORT
BALL END
x 1
MISCELLANEOUS COMPONENTS
FRONT BUMPER
x 1
FOAM BLOCK
x 1
.265
STEERING TURNBUCKLE 1.00": x 1
SCALE 1:1
1. TWIST THE BALL CUPS ONTO THE BLUE TITANIUM TURNBUCKLE
UNTIL YOU GET THE DIMENSION SHOWN.
BAG G
STEP 1
