USER MANUAL14
Software Controls
Reports Archived logs can be opened by either
browsing to the dened path or by selecting:
Tools > Log > Open Log
Select Wavelength
Userscandenethe
listofwavelengths
Wavelength Setup
Usethe<<and>>arrowstoselectthe
wavelengthsyouwanttoappearonthe
OPMbymovingthemtotheboxonthe
righthandside.
Power Threshold
SetsthelevelatwhichtheTRAFFIC
indicatorappearswhenusedasanLFI.
Import Saved Values
ImportssavedvaluesthatarestoredontheOpticalPower
Metertoareportlog(alsodonebyselectingTools>Import).
Select Measurement Type
Userscandenethelistof
wavelengths
The default path is:
C:\Documents and Settings\All Users\Documents\Westover Scientic\
FiberChek2\Archive\USBPowerMeterLogs
CHAPTER 3
Software
