C
ONNECTIONS
6
How to connect bridge mono mode.
Bridged mono is intended for driving loads with a total impedance
of 8ohms or greater to put the amplifier in bridged mono mode,
turn the amplifier off and slide the stereo-mono switch toward
the right.
Both outputs receive the signal from CH"1" with the output of
CH"2".
Keep the level control of CH"2" turned completely down.
(counterclockwise)
브릿지모노방식
모드스위치를브릿지모노에위치시키고스피커극성에주의하여결선
하여주십시오.채널2의볼륨은반시계방향으로완전히돌리고,채널1
볼륨으로적당한레벨로설정하여운용하십시오.
TRIPAC series or
STAGE PRO MIXER
PROFESSIONAL AUDIO MIXER 8.4.4.2
TRIPAC
NOT USE
To Next Page
