Ergo-Flex
Operating / Service Manual
CONTENTS
Any shipping damage should be documented and
reported immediately to the carrier or JEDMED.
NOTE
DESCRIPTION & INDICATIONS FOR USE
System: EF-N Slim (2.8mm diameter)
Qty Item Item No.
1 49-4928 Scope (EF-N Slim)
1 49-4980 Leakage Tester
1 49-4985 Ventilation Cap
1 49-4172 Karl Storz Adaptor
1 49-4170 Wolf Adaptor
OR
Carefully unpack all components. Verify contents and inspect for shipping damage.
Refer to next page for illustrations.
System: EF-N (3.4mm diameter)
Qty Item Item No.
1 49-4930 Scope (EF-N)
1 49-4980 Leakage Tester
1 49-4985 Ventilation Cap
1 49-4172 Karl Storz Adaptor
1 49-4170 Wolf Adaptor
Ergo-Flex laryngo-nasopharyngoscope is also referred
to as “device”, “instrument” and/or “scope” throughout
this manual.
NOTE
JEDMED’s Ergo-Flex laryngo-
nasopharyngoscope is a exible beroptic
endoscope designed for examining the
larynx, nasal cavity and nasopharynx. These
areas encompass the upper respiratory tract
from the nasal passages to the vocal chords.
Ergo-Flex scopes are intended to be used by
ENT physicians in an ofce setting for routine
ENT procedures.
Ergo-Flex is available in two sizes: the
3.4mm standard insertion tube diameter
(EF-N) and the 2.8mm diameter size for
pediatrics (EF-N Slim). The ergonomic
shape of this scope creates a well-balanced
instrument, maximizing user comfort.
Ergo-Flex contains a high ber-count image
bundle producing exceptional, high-resolution
images which are large, sharp and bright.
An industry-standard “B-cup” endoscope
eyepiece allows the user to look through the
scope, directly, or to indirectly observe the
eld by attaching an optional video camera
and endoscope coupler. Unsurpassed light
transmission also makes this scope ideal for
stroboscopic examinations.
Ergo-Flex is a quality-designed and
manufactured medical device. Given
reasonable care, this product will provide
many years of trouble-free service.
