CAUTION!
•
Hinge pins can break if overtightened during door
reinstall (Max Torque: 5.88 ft·lb/8N·m).Forinfor-
mation on off-road driving tips, see
page 175.
•
Do not overtighten Torx fasteners. Damage to the
vehicle’s parts will occur.
Use this QR code to access your digital
experience.
Outside rearview mirrors are mounted
on the doors. If you choose to remove
the doors, see an authorized dealer for
a replacement cowl-mounted outside
mirror. Federal law requires outside mir-
rors on vehicles for on-road use.
NOTE:
When front doors are removed, the message “Blind
Spot Alert Temporarily Unavailable” will display in the
instrument cluster display. Power Mirrors and Power
Door Locks will also be unavailable.
To remove the front doors, proceed as follows:
1. Roll down the glass window to prevent any damage.
2. Remove the hinge pin nut from the upper and lower
outside hinges (using a #T50 Torx head driver).
NOTE:
The hinge pin nuts can be stowed in the Fastener
Bin located under the rear seat.
3. Remove the plastic wiring access door under the
instrument panel by sliding the plastic panel along
the door frame toward the seats until the tabs are
detached.
NOTE:
Do not force open; this will break the plastic cover.
4. Pull up on the red locking tab to unlock the wiring
harness.
5. Push and hold down the black security tab under
the wiring harness, and lift the harness lever into
the open position.
Scan me
Hinge Pin Nut
Wiring Access Door
Closed Wiring Harness
1 — Red Locking Tab
2 — Wiring Harness Lever (Closed Position)
26 GETTING TO KNOW YOUR VEHICLE
