Cavity Cartridge Fuse Micro Fuse Description
* If Equipped
F100 30 Amp Pink – ESC-ECU & VALVES
F101 30 Amp Pink – Drivetrain Control Module (DTCM)
F102 – 15 Amp Blue DUAL USB PORT
F103 – 15 Amp Blue HD ACCY #3*
F104 – – Spare*
F105 – 10 Amp Red
Integrated Center Stack (ICS)/Heat Ventilation Air Conditioning
(HVAC)
F106 50 Amp Red – Electronic Speed Control (ESC)/PUMP MTR
F107 – 20 Amp Yellow TRAILER TOW STOP/TURN LT*
F108 – 15 Amp Blue HD ACCY #4*
F109 – 20 Amp Yellow TRAILER TOW STOP/TURN RT*
F110 30 Amp Pink – Power Inverter 150W*
F111 20 Amp Blue – TRAILER TOW BACKUP*
BULB REPLACEMENT
Replacement Bulbs, Names, And Part Numbers
In the instance a bulb needs to be replaced, this section includes bulb description and replacement part numbers.
NOTE:
See an authorized dealer for LED bulb replacement.
Interior Bulbs
Bulb Name Bulb Number
Automatic Transmission Indicator Lamp 658
Heater Control Lamps 194
SERVICING AND MAINTENANCE 331
