Cavity Cartridge Fuse Micro Fuse Description
* If Equipped
F75 – – Spare*
F76 – 20 Amp Yellow ECM (GAS)/PCM (DSL)
F77 – 10 Amp Red Heated Mirrors
F78 – – Spare*
F79 – 20 Amp Yellow SMART BAR CTRL MOD
F80 – 15 Amp Blue Powertrain Control Module (PCM)/Solenoid 1 2 Block Shift
F81 30 Amp Pink – REAR DEFROSTER (EBL)
F82 30 Amp Pink – FUEL HTR*
F83 60 Amp Yellow – GLOW PLUG*
F84 30 Amp Pink – UREA HTR CTRL UNIT*
F85 – 10 Amp Red PM SENSOR*
F86 – – Spare*
F87 – 10 Amp Red SUPPLY/PURGING PMP*
F88 20 Amp Blue – NOx SENSOR #1/#2*
F89 – 10 Amp Red
Steering Column Control Module (SCCM)/Cruise Control (CRUISE
CTL)/Digital TV (DTV)/Airbag Disable Lamp
F90 20 Amp Blue – TRAILER TOW PARK LMP*
F91 – 20 Amp Yellow Horn
F92 40 Amp Green – HD ACCY #2*
F93 40 Amp Green – HD ACCY #1*
F94 – – Spare *
F95 – – Spare*
F96 – 10 Amp Red PWR MIRROR SW
F97 – 20 Amp Yellow RADIO/TBM
F98 – 10 Amp Red SW BANK-HD ELEC/OFF ROAD
F99 – – Spare*
