NOTE:
When vehicle speed becomes too high to display the
pitch and roll, “- -” will display in place of the numbers,
and the graphic will be grayed out. A message indicat-
ing the necessary speed for the feature to become
available will also display.
Driver Assist — If Equipped
The Driver Assist menu displays the status of the ACC
system.
Push and release the up
or down arrow button
until the Driver Assist menu is displayed in the instru-
ment cluster display.
Adaptive Cruise Control (ACC) Feature — If Equipped
The instrument cluster display displays the current ACC
system settings. The information displayed depends on
ACC system status.
Push the ACC ON/OFF button (located on the steering
wheel) until one of the following displays in the instru-
ment cluster display:
Adaptive Cruise Control Off
When ACC is deactivated, the display will read “Adaptive
Cruise Control Off.”
Adaptive Cruise Control Ready
When ACC is activated but the vehicle speed setting
has not been selected, the display will read “Adaptive
Cruise Control Ready.”
Push the SET + or the SET - button (located on the
steering wheel), and the following will display in the
instrument cluster display.
ACC SET
When ACC is set, the set speed will display in the instru-
ment cluster.
The ACC screen may display once again if any ACC activ-
ity occurs, which may include any of the following:
•
System Cancel
•
Driver Override
•
System Off
•
ACC Proximity Warning
•
ACC Unavailable Warning
NOTE:
The instrument cluster display will return to the last
display selected after five seconds of no ACC display
activity
page 137.
Fuel Economy
Push and release the up or down arrow button
until the Fuel Economy icon is highlighted in the instru-
ment cluster display. Push and hold the OK button to
reset average fuel economy feature.
Toggle left
or right to select a display with or
without Current Fuel Economy Information.
•
Range – The display shows the estimated distance
(mi or km) that can be traveled with the fuel remain-
ing in the tank. When the Range value is less than
10 miles (16 km), the Range display will change to a
“LOW” message. Adding a significant amount of fuel
to the vehicle will turn off the “LOW” message and a
new Range value will display. Range cannot be reset
through the OK button.
NOTE:
Significant changes in driving style or vehicle loading
will greatly affect the actual drivable distance of the
vehicle, regardless of the Range displayed value.
•
Average – The display shows the average fuel
economy (MPG, L/100km, or km/L) since the last
reset.
•
Current – The display shows the current fuel
economy (MPG, L/100km, or km/L) while driving.
Trip Info
Push and release the up or down arrow button
until the Trip icon/title is highlighted in the instrument
cluster display, then push and release the left
or
right
arrow button to select Trip A or Trip B.
The Trip A and Trip B information will display the
following:
•
Distance
•
Average Fuel Economy
•
Elapsed Time
Hold the OK button to reset all the information.
Stop/Start — If Equipped
Push and release the up or down arrow button
until the Stop/Start icon/title is highlighted in the
instrument cluster display. The screen will display the
Stop/Start status.
Audio
Push and release the up or down arrow button
until the Stop/Start icon/title is highlighted in the
instrument cluster display. The screen will display the
Stop/Start status.
Phone Call Status
When a call is incoming, a Phone Call Status pop-up will
display on the screen. The pop-up will remain until the
phone is answered or ignored.
GETTING TO KNOW YOUR INSTRUMENT PANEL 103
3
