PO BOX 7231, COLORADO SPRINGS, COLORADO 80933 USA E-mAIL: jRDG@jEffROwLAND.COm www.jEffROwLAND.COm TELEPHONE (719) 473-1181
12
1 2 64 5 73
(1) INPUT INDICATORS: Inputs 1 through 5 have a small indicator light above the Input Selector
Buttons.
An indicator will illuminate blue when selected to show that the input is currently active.
(2) INPUT SELECTOR BUTTONS:
Pressing these buttons selects an input source (CD, tuner,
phono, etc.)
connected to the associated rear panel inputs (see Rear Panel Signal Connections
on page 14). To select a
desired input, press the corresponding Input Selector Button. When an
input is activated, the small, blue Input
Indicator above the Input Selector Button will illuminate.
Before attempting any system inter connection,
please familiarize yourself with the front panel
controls and indicators of the CONCERTO
Stereo Preamplifier. The descriptions refer to
the illustration below.
