PO BOX 7231, COLORADO SPRINGS, COLORADO 80933 USA E-mAIL: jRDG@jEffROwLAND.COm www.jEffROwLAND.COm TELEPHONE (719) 473-1181
18
Overall Gain 20 dB
Gain Range 99.5 dB, 199 Equal Increments
Gain Resolution 0.5 dB, +/- 0.03 dB Over Entire Range
Frequency Response 10 Hz – 280 kHz, -3 dB
Maximum Input Level 15 volts RMS @ 0 dB Gain
Maximum Output Level 13.5 volts RMS
CCIF Intermodulation Distortion, 19/20 kHz < .002%
Output Noise Level
43 Microvolts, Unweighted
20 Hz – 20 kHz Bandwidth, 0 dB Gain
Common Mode Rejection Ratio > 90 dB, 20 Hz – 20 kHz
Input Impedance 40K ohms Balanced or Unbalanced
Channel Separation > 90 dB, 20 Hz – 20 kHz
Inputs
2 pair Balanced (XLR)
1 pair Unbalanced (RCA) Unity Gain (Bypass)
3 pair Unbalanced (RCA)
Outputs
2 pair Balanced (XLR) Line Level
Power Consumption 7 watts
Preamplifier Weight
21 lbs. / 9.8 kg
Overall Preamplifier Dimensions (H) x (W) x (D)
3.2” x 17.3” x 12.9”
80mm x 440mm x 328mm
SPECIFICATIONS
OWNERS MANUAL CONCERTO STEREO PREAMPLIFIER
