25
SWITCH POSITION LOAD RESISTANCE (ohms) PHONO CARTRIDGE TYPE
1: OFF | 2: OFF 47K MM OR HIGH OUTPUT MC
1: ON | 2: OFF 100 MC ONLY
1: OFF | 2: ON 400 (Default) MM OR HIGH OUTPUT MC
1: ON | 2: ON 85 MC ONLY
SWITCH POSITION GAIN (dB) PHONO CARTRIDGE TYPE
1: OFF | 2: OFF 44 MM ONLY
1: ON | 2: OFF 55
SOME MM, HIGH OUTPUT MC
1: OFF | 2: ON 62 (Default) MC ONLY
1: ON | 2: ON 64.5 MC ONLY
FIGURE 11: Table 1, Load Resistance Settings
FIGURE 12: Table 2, Gain Settings
CAUTION:
Do not select the 47K ohm Load Switch
Position unless a turntable, phono cartridge or
RCA “shorting” plug is connected to INPUT 2/PHONO! If a
phono
turntable or RCA “shorting” plug is not connected
to INPUT 2/PHONO and the card is installed, set the Load
Switch Position to any position except 47K. The 47K ohm
Load
Switch
Position is used for Moving Magnet
or High
Output Moving Coil phono
car
tridges only!
