Jenn-Air JDS9860ACP - User Manual

Questions and Answers

S
sydneydanielAug 6, 2025
What to do if my Jenn-Air Ranges burner won't ignite?
- L
  lisaacevedoAug 6, 2025
  If the burner on your Jenn-Air Ranges isn't igniting, several factors could be at play. First, ensure your range is receiving 120 VAC by verifying the voltage at the wall outlet. A dirty electrode or burner cap can also prevent ignition, so try cleaning them. Other potential causes include faulty wiring or a bad connection at the burner electrode and electrode socket, micro switch contacts not closing, or a non-operative spark module. Check the wiring against the appropriate wiring diagram to ensure all terminals and connections are correct and tight. If the electrode is cracked or broken, replace it. Check the module according to testing procedures information.
R
Rick RamosAug 11, 2025
How to fix Jenn-Air Ranges burners that won't ignite?
- L
  lfernandezAug 11, 2025
  If the burners on your Jenn-Air Ranges aren't igniting and there's no spark, it could be due to several reasons. Start by cleaning the burner cap to ensure a good ground. Low gas pressure could also be the culprit; verify the pressure is 4" WCP for natural gas or 10" WCP for LP gas. Additionally, a clogged burner port can prevent ignition, so clean the burner cap. If these steps don't work, the spark module might be weak or has failed and should be replaced.
A
April WalkerAug 16, 2025
Why is my Jenn-Air Ranges bake element not working?
- D
  Donald LoweryAug 16, 2025
  If the bake element in your Jenn-Air Ranges isn't working, it could be due to an open bake element. Check the element for continuity and replace it if it has failed. Also, inspect for any loose or broken wire connections and ensure all connections are clean and tight, replacing any broken wires. Finally, verify 240 VAC at the bake element to check for an open bake relay.
H
Hunter CarrollAug 21, 2025
What to do if my Jenn-Air Ranges oven won't bake or broil?
- I
  ihollowayAug 21, 2025
  If your Jenn-Air Ranges oven isn't operating in bake or broil mode, begin by checking for 120 VAC at the control. If there's no voltage, check the power source. If there is voltage to the control but no voltage from control to the ignitor, the control may need to be replaced. Also, inspect for any loose or broken wires, ensuring all connections are clean and tight; replace any broken wires.
L
Lisa WilliamsAug 27, 2025
Why is there no spark on my Jenn-Air Ranges ignitor?
- N
  Nicholas TannerAug 27, 2025
  If you're experiencing no spark or random sparks at one ignitor on your Jenn-Air Ranges, a few things could be the cause. Check for a cracked ignitor or pinched ignitor wire and replace the ignitor lead or electrode if needed. Poor continuity to the burner cap can also be an issue, so clean the burner cap and lead. Additionally, a bad ground connection or lack of continuity to ground or the ignitor can cause this problem. Tighten the ground connection and correct any breaks in the ground path from the ignitor path to the unit ground path. Finally, check for a cracked or broken ignitor extension lead and replace the ignitor lead if necessary.
M
Melissa WardAug 31, 2025
What to do if Jenn-Air Ranges keeps sparking after being turned off?
- G
  Gregory PetersenAug 31, 2025
  If your Jenn-Air Ranges continues to spark after the knob is turned to the OFF position, it could be due to a shorted valve switch or harness. In this case, replace the switch or harness. Also, check if the switch has slipped off the valve; carefully reposition the switch on the valve and rotate it from OFF to high several times to verify the switch is not broken.

Summary

Important Information

Important Notices for Servicers and Consumers

Key safety warnings and contact information for service support.

Recognize Safety Symbols, Words, and Labels

Explanation of safety symbols (Danger, Warning, Caution) and their meanings.

Important Safety Information

What to Do If You Smell Gas

Procedure to follow in case of a gas leak, including immediate actions and contact information.

All Appliances

General safety precautions applicable to all appliance operations and usage.

Important Safety Information

Surface Cooking Units

Safety guidelines for using the surface cooking elements and cookware.

Safety Practices for Servicer

Essential safety precautions for technicians performing service on the appliance.

Receiving Oven

Instructions for receiving, installing, and connecting the oven safely.

Important Safety Information

Connecting Range to Gas

Guidelines for safely connecting the gas supply line to the appliance.

Using the Oven

Safety advice and precautions for operating the oven and its components.

Ovens

Specific safety instructions related to oven operation and care.

Self-Cleaning Ovens

Safety precautions and instructions for using the self-cleaning function.

Glass;Ceramic Cooking Surfaces

Safety guidelines for cleaning and using the glass or ceramic cooktop.

Important Safety Information

Ventilation Hoods

Safety and cleaning instructions for ventilation hoods.

Oven Fires

Procedure to follow in case of an oven fire to ensure safety.

Precautions

General safety precautions for using the range top and its surfaces.

Product Safety Devices

Pressure Regulator

Explanation of the pressure regulator's function and importance in gas ranges.

Gas Burner Orifices

Information on gas burner orifices and their role in gas supply.

Grounded Oven Frame

Importance of proper grounding for electrical safety and shock prevention.

General Information

Cooking Nomenclature

Explanation of model number coding for appliance identification.

Specifications

Reference to individual technical sheets for detailed product specifications.

General Information

Placement of the Oven

Guidelines for properly placing the freestanding range for safe operation.

Do Not Block Air Vents

Importance of keeping air vents clear to prevent overheating.

Location of Model Number

Instructions on how to find the model and serial number for service.

Model Identification

Information on identifying the appliance model and recording details.

Service

Advice on locating authorized service and warranty information.

Parts and Accessories

Information on how to purchase replacement parts and accessories.

Extended Service Plan

Details about the extended service plan for long-term protection.

Range Description

Diagram and labels identifying key components of the slide-in range.

Troubleshooting Procedures

Troubleshooting Chart

Table listing common problems, possible causes, and corrective actions for the range.

Troubleshooting Procedures

Fault Code Chart

List of fault codes, their descriptions, and components to troubleshoot or replace.

Troubleshooting Procedures

Oven Sensor and Meat Probe Charts

Tables showing resistance values for oven sensors and meat probes at various temperatures.

Testing Procedures

Component Testing Procedures

Procedures and expected results for testing individual range components.

Testing Procedures

Oven Control Testing Procedures

Steps for changing factory default options and testing oven control functions.

Testing Procedures

Control Panel Assembly

Testing procedures for the control panel, including pad and trace measurements.

Testing Procedures

Relay Logic

Chart detailing relay operation for different cooking modes and functions.

Testing Procedures

Quick Test Mode for Electronic Oven Control (EOC) II

Procedure to enter and perform quick tests on the electronic oven control.

Testing Procedures

Description of Fault Codes

Explanation of fault codes and their corresponding components for troubleshooting.

Disassembly Procedures

Removing and Replacing Range

Steps for safely removing and reinstalling the entire range unit.

Cartridge Assembly (Select Models)

Instructions for removing and installing cooktop cartridges.

Top Burner

Procedure for removing and reinstalling a top burner assembly.

Top Burner Lower Assembly

Steps to remove the top burner lower assembly for servicing.

Manifold and Top Burner

Procedure for disassembling the manifold and top burner components.

Regulator

Instructions for removing and reinstalling the gas pressure regulator.

Burner Switch

Procedure for removing and reinstalling the burner switch.

Spark Module

Steps to remove and replace the spark module for ignition system service.

Disassembly Procedures

Maintop Assembly

Detailed steps for removing the maintop assembly of the range.

Control Panel

Instructions for removing and reinstalling the control panel.

Electronic Control

Procedure for removing and reinstalling the electronic control module.

Bottom Access Panel

Steps for removing and reinstalling the bottom access panel.

Indicator Lights

Procedure for removing and reinstalling indicator lights on the control panel.

Disassembly Procedures

Meat Probe Receptacle (Select Models)

Instructions for removing and reinstalling the meat probe receptacle.

Back Panel

Procedure for removing and reinstalling the back panel of the appliance.

Cooling Fan

Steps for removing and reinstalling the cooling fan assembly.

Transformer

Procedure for removing and reinstalling the transformer component.

Bake Element

Instructions for removing and reinstalling the oven bake element.

Broil Element

Steps for removing and reinstalling the oven broil element.

Downdraft Blower Motor (Select Models)

Procedure for removing and reinstalling the downdraft blower motor.

Oven Sensor

Instructions for removing and reinstalling the oven sensor.

Front Side Trim

Procedure for removing and reinstalling the front side trim pieces.

Oven Light Bulb;Oven Light Socket

Steps for replacing the oven light bulb and socket assembly.

Disassembly Procedures

Oven Light Switch

Procedure for removing and reinstalling the oven light switch.

Oven Vent;Smoke Eliminator

Instructions for removing and reinstalling the oven vent/smoke eliminator.

Hi-Limit Thermostat

Steps for removing and reinstalling the hi-limit thermostat.

Oven Door Latch

Procedure for removing and reinstalling the oven door latch assembly.

Convection Fan

Instructions for removing and reinstalling the convection fan motor.

Disassembly Procedures

Oven Door Removal

Instructions for safely removing the oven door from the appliance.

Oven Door Hinge

Procedure for removing and reinstalling the oven door hinge receiver.

Door Disassembly

Detailed steps for disassembling the oven door, including glass and handle.

Installation Instructions (Model JDS8850 A**)

INSTALLATION DRAWINGS

Diagrams showing required clearances and installation dimensions for the range.

ANTI-TIP DEVICE INSTALLATION

Instructions for installing the anti-tip bracket to prevent range tip-over.

Installation Instructions (Model JDS8850 A**)

CONNECTING THE RANGE TO ELECTRIC SUPPLY

Guidelines for connecting the range to the appropriate electrical supply and wiring.

Installation Instructions (Model JDS8850 A**)

CONNECTING THE RANGE TO GAS SUPPLY

Instructions for safely connecting the range to the natural or LP gas supply.

Use Information (Model JDS8850 A**)

CONTROL PAD OPERATION

Explanation of how to operate the control panel pads and their functions.

CONTROL OPTIONS

Description of adjustable control settings and how to change them.

SETTING CONTROL FUNCTIONS

Guidance on setting various oven functions and timers.

CLOCK PAD

Instructions for setting and recalling the clock time on the control panel.

Use Information (Model JDS8850 A**)

AUTO SET PAD

How to use the Auto Set pad for automatic temperature and time settings.

BAKE PAD

Instructions for using the Bake pad for baking and roasting functions.

CONVECT BAKE PAD; CONVECT ROAST PAD

How to use convection bake and roast functions with temperature settings.

Use Information (Model JDS8850 A**)

BROIL PAD

Instructions for using the Broil pad for top browning and broiling.

COOK TIME; STOP TIME PADS

How to program automatic start and stop times for oven cooking.

QUICK PREHEAT PAD

How to use the Quick Preheat pad to reduce oven preheating time.

CLOCK CONTROLLED OVEN COOKING

Notes and recommendations for using the oven with delayed cooking functions.

Use Information (Model JDS8850 A**)

KEEP WARM PAD

How to use the Keep Warm pad to keep food warm or warm plates.

MEAT PROBE PAD

Instructions for using the meat probe to roast and bake items to desired temperatures.

BREAD PROOFING PAD

How to use the Bread Proofing pad for proofing yeast dough.

Use Information (Model JDS8850 A**)

OVEN TEMPERATURE ADJUSTMENT

How to adjust oven temperature settings for more accurate cooking.

Care Information

CLEAN PAD

Instructions for setting immediate or delayed self-clean cycles for the oven.

TO SET FOR IMMEDIATE START

Steps to initiate an immediate self-clean cycle for the oven.

TO CANCEL SELF-CLEAN

Procedure to cancel a self-clean cycle, including safety precautions.

TO SET FOR DELAY START

Steps to program a delayed self-clean cycle for the oven.

Care Information

CLEANING PROCEDURES

General guidelines and precautions for cleaning the appliance components.

CLOCK AND CONTROL PAD AREA

How to clean the control panel and display area safely.

CONTROL PANEL

Instructions for cleaning the control panel, including for stubborn soil.

CONTROL KNOBS

Procedure for removing, cleaning, and reinstalling control knobs.

COOKTOP & SEALED GAS BURNER CARTRIDGE

Cleaning instructions for the cooktop and porcelain enamel surfaces.

BROILER PAN AND INSERT

How to clean the broiler pan and insert, including soaking and washing methods.

DOOR HANDLE PLASTIC FINISHES

Cleaning instructions for the plastic door handle finish.

OVEN WINDOW & DOOR GLASS

Guidelines for cleaning the oven door glass without causing damage.

OVEN INTERIORS

Reference to self-clean cycle instructions for oven interiors.

OVEN RACKS

How to clean oven racks, including dealing with stubborn soil.

Care Information

SEALED GAS BURNER ASSEMBLY

Instructions for cleaning the sealed gas burner assembly, including ports.

STAINLESS STEEL (SELECT MODELS)

Guidelines for cleaning stainless steel surfaces, including soil removal and polishing.

GRILL ASSEMBLY BASIN PORCELAIN

Cleaning instructions for the grill assembly basin and porcelain components.

GRILL GRATES CAST ALUMINUM COATED WITH NON-STICK FINISH

How to clean grill grates, including special care for non-stick finishes.

GRILL BURNER

Instructions for cleaning the grill burner after each use.

GREASE CUP

How to locate, empty, and clean the grease cup.

LP Conversion Instructions

GAS CONVERSION

General information on converting the range between natural gas and LP gas.

Appliance Pressure Regulator Conversion

Steps to convert the appliance pressure regulator for different gas types.

LP Conversion Instructions

ORIFICE CONVERSION

Instructions for converting burner orifices and air shutters for different gas types.

LP Conversion Instructions

SURFACE BURNER HEADS AND BURNER BASES

Cleaning and replacement instructions for surface burner heads and bases.

HOW TO REMOVE RANGE FOR CLEANING AND SERVICING

Procedures to safely remove the appliance for cleaning or servicing.

SERVICE-PARTS INFORMATION

Guidance on obtaining service or replacement parts for the range.

Jenn-Air JDS9860ACP Specifications

General

Brand	Jenn-Air
Model	JDS9860ACP
Burners	5
Convection	Yes
Self-Cleaning	Yes
Color	Stainless Steel
Width	30 inches
Weight	250 lbs
Cooktop Type	Gas
Number of Burners	5
Wi-Fi Connectivity	No
Depth	28 in.
Height	36 inches
Control Type	Electronic
Fuel Type	Dual Fuel (Gas Cooktop, Electric Oven)
