Testing Procedures
!
WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to vent hood before servicing, unless
testing requires power.
©2004 Maytag Services 16023510 11
Model Numbers Component Test Procedure Results
All Halogen lights
Press light switch once ................................
.
(measure voltage at light socket).................
.
Press light switch again ...............................
.
(measure voltage at light socket).................
.
Press light switch once ................................
.
(measure voltage at light socket).................
.
Press and hold light switch for 3 seconds....
.
(measure voltage at light socket).................
.
Lights illuminate to full brightness
(120 VAC).
Lights extinguish (turn off)
(0 VAC).
Lights illuminate to full brightness
(120 VAC).
Lights illuminate to half brightness
(63 VAC)
All Halogen light socket Remove one wire from receptacle and test
resistance of terminals.................................
.
Measure voltage at light ..............................
.
Indicates continuity with bulb screwed in.
120 VAC. If no voltage is present at
light, check wiring or light switches.
JXT9030CDP,
JXT9036CDP,
JXT9048CDP,
JXT9130CDP,
JXT9136CDP
Heat lamp socket Remove one wire from receptacle and test
resistance of terminals.................................
.
Measure voltage at light ..............................
.
Indicates continuity with bulb screwed in.
120 VAC. If no voltage is present at
light, check wiring or light switches.
JXT8030ADS,
JXT8036ADS,
JXT8042ADS,
JXT8136ADS,
JXT8142ADS,
JXT5830AD*,
JXT5836AD*
Capacitor Disconnect wires. Measure resistance by
placing red meter lead on positive
terminal, black meter lead on negative
terminal .......................................................
.
Reverse meter leads on capacitor
terminals......................................................
.
Check for a short by placing one lead on a
terminal and the other to ground..................
.
Meter reading should gradually increase
(capacitor charging).
Meter reading should gradually decrease
(capacitor discharging).
Infinity (if shorted, replace capacitor).
JXT9030CDP,
JXT9036CDP,
JXT9048CDP,
JXT9130CDP,
JXT9136CDP
Capacitors
(2 ea, red wires input,
yellow wires output)
Obtain analog multi-meter. Disconnect
wires. Measure resistance by placing red
meter lead on positive terminal, black
meter lead on negative terminal ..................
.
Reverse meter leads on capacitor
terminals......................................................
.
Check for a short by placing one lead on a
terminal and the other to ground..................
.
Rating: 4 microfarad
Meter reading should gradually increase
(capacitor charging).
Meter reading should gradually decrease
(capacitor discharging).
Infinity (if shorted, replace capacitor).
JXT8030ADS,
JXT8036ADS,
JXT8042ADS,
JXT8136ADS,
JXT8142ADS,
JXT5830AD*,
JXT5836AD*
Transformer Check for input voltage by placing red
lead on black wire (input voltage), black
lead on white wire (neutral)..........................
.
Check transformer outputs by placing leads
on black (input voltage) and white (neutral),
then set fan speed as follows:
6 ..................................................................
.
5 ..................................................................
.
4 ..................................................................
.
3 ..................................................................
.
2 ..................................................................
.
1 ..................................................................
.
120 VAC
113 VAC
88 VAC
80 VAC
66 VAC
50 VAC
33 VAC
JXT9030CDP,
JXT9036CDP,
JXT9048CDP,
JXT9130CDP,
JXT9136CDP
Transformer Check for input voltage by placing red
lead on brown wire (input), black lead on
light blue wire (neutral) ................................
.
Check transformer outputs by placing
meter leads on:
Brown (Input voltage) ..................................
.
Black ...........................................................
.
Red..............................................................
.
Orange ........................................................
.
Yellow..........................................................
.
Green (Lowest setting) ................................
.
120 VAC
120 VAC
106 VAC
97 VAC
90 VAC
81 VAC
74 VAC
