CDR6221 OPERATION

The built-in SWC Interface is compatible with PAC steering wheel control modules.

The PAC SWI-RC is recommended. A third-party adapter must be used in order for the

XDVD600 to be compatible with any steering wheel controls. The following controls are

available for most vehicles.

Note: Not all OE steering wheel functions may be supported by the XDVD600.

1. Volume Up (+) 4. Preset (+) 7. Seek/Track Up (+) 10. BT Talk

2. Volume Down (-) 5. Preset (-) 8. Seek/Track Down (-) 11. BT End

3. Mute 6. Mode 9. Band

PAC SWI-RC Installation Hints

1. Set "Radio Select Switch". Set the SWI-RC to position 7 - "Pioneer/Other/Sony".

2. To program, use the Pioneer/Sony/Other radio function mapping order for CDR171

units.

3. When programming the SWI-RC, if a function is not supported (or not desired), then

the

function MUST be skipped as per the PAC SWI-RC instructions.

Func-

tion

Order

Function

Mapping

SWI-RC (3.3VDC Reference)

Center Pin (Ring) Volt-

age

(Function Select)

Tip Pin Voltage

1 Volume + H 5.0v 2.07

2 Volume - H 5.0v 2.32

3 Mute H 5.0v 1.01

4 Preset + L 0.0V 1.54

5 Preset - L 0.0V 1.81

6 Source H 5.0v 0.60

7 Seek + / Track + H 5.0v 1.54

8 Seek - / Track - H 5.0v 1.81

9 Band H 5.0v 2.73

10 BT Talk L 0.0V 0.60
