8
DMX5020
CONTROLS AND INDICATORS
DMX5020
AV INPUT
BAND
MENU
MUTE
Bluetooth
4VRMS Line Out
OPEN
10
9
8
6
7
5
4
3
21
DMX5020 Controls and Indicators
1. LCD Screen and Touch Screen:
Touch icons on this screen to access menus or control functions.
2. Remote Sensor:
Used to receive command signals from the remote control.
3. AV IN Connector:
This connector accepts a 3.5 mm jack through which signals from various
audio/video devices can be applied to the unit.
4. MicroSD Card Slot:
Used to insert microSD cards containing music/video les (MP3, AAC,
MPEG, etc.).

Jensen DMX5020 Specifications

General

Brand	Jensen
Model	DMX5020
Category	Car Receiver
Language	English
