Jensen VM9312 User Manual

5
VM9312
TILT
WIDE
CLOSE
AS/PS
BAND
DISP
OPEN
160
Watts
7
LO/DX
EJECT
VM9312
15
14
13
12
16
8
6
5
10 11
9
PRESS AUDIO
SRC
MUTE
1
2
4
3
17
SAT
READY
CONTROLS AND INDICATORS
Button Operation
1. OPEN
Press to activate the automatic mechanical system and move
the TFT monitor into viewing position. Press again to close
the TFT.
2. WIDE/DISP
Press to adjust the display aspect of the picture to one of two
settings: Full or Normal.
With the monitor closed, press the DISP button to cycle
through information available on the LCD screen.
3. PICTURE/AS/PS
Press to adjust the Brightness and Contrast. Press the
AUDIO button (5) to move between Brightness to Contrast.
Turn the rotary encoder (5) to adjust the setting for the
selected option.
With the monitor closed, press AS/PS to automatically store
strong radio stations in the six preset channels in the current
band.
4. TILT/BAND
Press to activate the tilt function. Use the joystick to make
adjustments while the red tilt icon is flashing. Press once to
adjust the downward tilt angle of the screen one step at a
time or press and hold to adjust the angle in a continuous
motion.
With the monitor closed, press the BAND button to change
the AM, FM or SAT band.
5. AUDIO/LO/DX
Rotate to adjust the volume. Press and release to enter and/
or confirm audio settings. Press and hold to activate the Local
(LOC) setting.
6. SRC
Press once to select playing mode.
7. LCD Display
8. MUTE
Press to silence the receiver. Press again to resume previous
volume level.
NOTE: The VM9312 features Softmute, which will allow
the volume to increase or decrease gradually when the
MUTE function is activated or deactivated.
