Jesco MEMDOS E - Page 10

B
98ca.
36,5
30
40
177
121,5
130

C
D
79
124ca.
L A L
11

Dimensional drawing MEMDOS E/DX 160...380
Type A B C D L* D with ATEX motor
E 160..0.260 278 148 317 469 approx. 22 632
DX 160..0.260 278 148 317 486 approx. 22
E 300...380 318 153.5 320 469 approx. 22 632
DX 300...380 318 153.5 320 486 approx. 22
* Dimension L for glue-in connection, internal ø 20, all dimensions in mm
268~
133
177
124
250~
130
Dimensional drawing MEMDOS E 160...380 ATE
10 | Operation & Maintenance Instructions | Dimensional drawings
