Jesco MEMDOS E - Technical Data ATE Servomotor MEMDOS E (Optional)

5.2 Technical data ATE servomotor MEMDOS E (optional)
Reversible servomotor with self-locking step-down gear. Connections via cable glands. Angle of rotation
limited by two internal limit switches.
Servomotor NK 1510 NK 1510-PMR-NK
Part No. 79466 79468 79467 79469
MEMDOS E E4 ... 380
Voltage 230 V AC,
50/60 Hz
115 V AC,
50/60 Hz
230 V AC,
50/60 Hz
115 V AC,
50/60 Hz
Power consumption 7 VA
Regulation
time
50 Hz 45 s
60 Hz 39 s
Regulation bevel 270° ⇔ 0...100%
Protection class IP 65
Ambient temperature -15 ... +60 ℃
Weight 2.5 kg
Inputs
Control 3-point step control 0(4) ... 20 mA
Working resistance
at 0/4...20 mA
- 250 Ω
Outputs
Position feedback signal for
remote display
0...1000 Ohm, max. 2 W 0(4) ... 20 mA
0(2) ... 10 V
See the enclosed operating instructions for the ATE servomotor for further technical data.
14 | Operation & Maintenance Instructions | Technical data
