Jesco MEMDOS E - Page 39

Spare parts sets MEMDOS E/DX 4...26
c
a
d
hg
d
e
f
b
i k
b
a
a
a
a
d
b
e
e
e
Spare parts sets for valves
Consisting of:
a Flat gaskets
b Valve balls
c * Springs
d Valve seats
e O-rings
i Diaphragm
* spring-loaded valve only
Material Double-ball valve Spring-loaded valve
PVC / Glass / FPM 29750 37336
PVC / Glass / EPDM 33698 37337
PP/ Glass / FPM 27750 37336
PP/ Glass / EPDM 33698 37337
PVDF / PTFE / PTFE 35572 37341
PVDF / PTFE / FPM 33856 37338
Stainless steel / PTFE 29751 37339
Complete valves for MEMDOS E/DX 4...26
Material
g Double-ball valve f Spring-loaded valve
Suction valve Discharge valve Suction valve Discharge valve
PVC / Glass / FPM 20890 20891 25087 25088
PVC / Glass / EPDM 33497 33498 33499 33500
PP/ Glass / FPM 35605 35606 35262 35263
PP/ Glass / EPDM 34647 34648 34733 34809
PVDF / PTFE / PTFE 28111 28112 29385 29384
PVDF / PTFE / FPM 33703 33704 34370 34371
Stainless steel / PTFE 24029 24030 25089 25090
Spare parts | Operation & Maintenance Instructions | 39
