ILLUSTRATION OF HAZARD REGION
Arrow shows the directions of movement in the danger area.
SPINDLE
SADDLE
C
R
O
S
S
S
L
I
D
E
Item Name
1
Chip Guard (moveable guard)
2
Chuck Guard
3
Heanend Guard
4
Rear Guard
5 The area between the leadscrew
and second rod
1
2
3
4
5
