MAIN SPECIFICATIONS
PRINCE 1330/1340
MODEL 1330 1340
Height of center 165mm. (6.5")
Swing over bed 330mm(13”)
Distance between centers 750mm(30”) 1000mm. (40")
Swing over cross slide 190mm(7.5”)
Swing in gap 495mm. (19.5")
Width of gap in front of faceplate 150mm. (6")
Spindle nose Camlock D-1-4
Spindle bore 35mm (1.375")
Spindle bore taper M.T. No. 4-1/2
Taper of center M.T. No. 3
Spindle speed; Steps: 8(optional 16)
Ranges; (8) 105, 175, 260, 395, 610, 915, 1320 2000 rpm.
Ranges (16) 53, 88, 105, 130, 175, 198, 260, 305, 395, 458
610, 660, 915, 1000, 1320, 2000 rpm.
VS-model; Steps: 2 Infinitely variable; Forward/Reverse.
Low speed ranges: 40-500 rpm.
High speed ranges: 200-2500 rpm.
Main motor; Standard model; 2.25kw (3HP)
Optional model; 2.25/1.12kw (3/1.5HP)
Varispeed model 1.5kw(2HP)
Width of bed 190mm. (7.5")
Length of bed 1380mm. (54.25") 1650mm. (65")
Cross slide travel 190mm. (7.5")
Top slide travel 90mm. (3.5")
Tailstock travel 110mm. (4.375")
Tailstock barrel diameter 40mm. (1.56")
Leadscrew diameter 22.22mm. (7/8")
Leadscrew pitch 4mm. or 8TPI. Optional: 6mm or 4TPI.
Inch Gearbox 14 & 0.5-6mm
Metric Gearbox 18&0.45-7.0mm
Number & range of Metric threads
Universal Gearbox 31 & 0.2-7.0mm
Inch Gearbox 32 & 4-56TPI
Metric Gearbox 24 & 4-28TPI
Number & range of Imperial
threads
Universal Gearbox 36 & 4-72TPI
Number & range of Module
t
hreads
Universal Gearbox 18 & 0.3~-3.5mm
Number & range of DP. threads Universal Gearbox 21 & 8-44 D. P.
Range of longitudinal feeds 0.038~0.254mm, 0.0015"~0.01", Opt.: 0.02-0.52 mm, 0.0008"-0.0205"
Range of cross feeds 0.012~0.090mm, 0.0005"~0.0035", Opt.: 0.006-0.170 mm, 0.00023"-0.0067"
Approx. Net/Gross weight 620/ 750kgs (1364/1650 Lbs.) 670/820kgs (1474/1804 Lbs.)
Packing sizes (L.x W. x H.) 1624 x 760 x 1473mm (64" x 30" x 58") 1930 x 760 x 1473mm (76" x 30" x 58")
STANDARD EQUIPMENT & ACCESSORIES
SUPPLIED WITH LATHE:
• Motor and relative electric control system.
• Speed meter of spindle (Varispeed only).
• Coolant system.
• 4-way toolpost, Max. toolholder size 13x13 mm.
(1/2" x 1/2").
• Threading dial indicator (Metric or Imperial one only).
• Centers sleeve and two centers .
• Levelling blocks and screws.
• Service tools and toolbox.
• Instruction and spare parts manual
OPTIONAL EQUIPMENT & ACCESSORIES MAY
UPPLIED AS OREDRS:
• 3-jaw universal chuck.
• Full length splash guard.
• 4-jaw independent chuck.
• Quick change toolpost.
• Steady rest.
• Chip safety guard.
• Follow rest.
• Dual Inch/Metric dials for cross and top slides.
• Slotted faceplate.
• Rotating center.
• Chuck safety guard.
• Halogen worklamp.
• Leadscrew cover.
• Micrometer bedstop.
• Chip Tray
