Operation Manual
Total 21
page 18
When the foundation is completely dry, the machine could be laid down on the adjustable
pad. Concrete could be filled when screw bolts are placed. Fastening screw bolts after
concrete is completely dry. Leveling the machine first, required tolerance should not be over
0.04/1000 both in horizontal and cross plane. Checking all items of the accuracy as per the
table sheet of the certificate. Accuracy value for each checked item must not be over the
required value.
6.3 Preparation before machine running:
A strict checking, testing and try cutting of the machine have been made before machine
delivery. No adjustment of the machine itself is necessary. Before machine running, clean all
surfaces of the machine first by using cloth with kerosene or gasoline, checking all lubrication
points then turn the main switch of the machine to the “on” position, running the machine with
middle or slow speed and checking all revolution direction is correct, operating levers are in a
correct position, checking machine noise and working temperature are all ok. The machine
should be running for a certain period of time, then it could be used if no any un-normal
condition happened.
7 Use and operation of the machine:
7.1 For the operating levers, handles, electric switches and buttons, please refer to the diagram 1
and diagram 4..
7.2 Mounting and dismounting of tool cutters:
The machine equipped with a tool dismounting device to be controlled by a knob ( 12 ). Push
forward the knob ( 12 ) to the spindle box direction when tool mounting is required. As for
dismounting tool cutters, pull out the knob ( 12 ), hold the tool cutter by left hand, meanwhile,
turn the feed lever ( 3 ) by right hand, then the spindle quill goes up rapidly, the tool cutter will
fall down until tool taper shank strokes the shaft of spindle.
In case too tight mesh between tool shank and spindle taper and the tool cutter could not fall
down after several strokes, then you have to use the normal way by using a taper wedge to
dismounting the tool cutter.
Warning: The knob ( 12 ) must not be pulled out while tool mounting or machine running,
otherwise, the spindle will goes up quickly which results tool cutter falls down. It
is really dangerous.
