Jet GHD-25 User Manual

No. Part no. Descirption Size Qty.
1
GHD25-1-001 Knurled nob 1
2
GHD25-1-002 Knurled screw bolt 1
3
GHD25-1-003 Scaled screw 1
4
GHD25-1-004 Scaled nut 1
5
GHD25-1-005 Positioning block 1
6
GHD25-1-006 Support for the indicator 1
7
GHD25-1-007 Scaled indicator sheet 1
8
GHD25-1-008 Spindle 1
9
GHD25-1-009 Spindle cover 1
10
GHD25-1-010 Bearing 2
11
GHD25-1-011 Washer 1
12
GHD25-1-012 Bearing 1
13
GHD25-1-013 Scaled clamper 1
14
GHD25-1-014 Spindle quill 1
15
GHD25-1-015 Spline quill 1
16
GHD25-1-016 Bearing 1
17
GHD25-1-017 Nut 1
18
GHD25-1-018 Transmission shaft 1
19
GHD25-1-019 Bearing 1
20
GHD25-1-020 Bearing cover 1
21
GHD25-1-021 Bearing 1
22
GHD25-1-022 Gear(8) 1
23
GHD25-1-023 Gear(9) 1
24
GHD25-1-024 Bearing 1
25
GHD25-1-025 Washer 18 1
26
GHD25-1-026 Nut 1
27
GHD25-1-027 Bearing cover 1
28
GHD25-1-028 Knob 2
29
GHD25-1-029 Lever 2
30
GHD25-1-030 Lever seat 1
31
GHD25-1-031 Positioning Washer 1
32
GHD25-1-032 Fork shaft 1
33
GHD25-1-033 Fork 1
34
GHD25-1-034 Right Lever 1
35
GHD25-1-035 Bushing 1
36
GHD25-1-036 Lever seat 1
37
GHD25-1-037 Positioning washer 1
38
GHD25-1-038 Fork shaft 1
39
GHD25-1-039 Left lever 1
40
GHD25-1-040 Block 1
41
GHD25-1-041 Sleeve 1
42
GHD25-1-042 Positioning block 1
43
GHD25-1-043 Knurled handle 1
44
GHD25-1-044 Bushing 1
45
GHD25-1-045 Positioning shaft 1
46
GHD25-1-046 Cover 1
47
GHD25-1-047 Spindle box 1
Part List for GHD-25 DRILL PRESS
