Jet GHD-25 User Manual

No. Part no. Descirption Size Qty.
1
GHD25-2-01 Base 1
2
GHD25-2-02 Retainer ring 16 1
3
GHD25-2-03 Oil plug M16X1.5 1
4
GHD25-2-04 Cover plate
1
5
GHD25-2-05 Screw M6X10
4
6
GHD25-2-06
Cooling pump 0.18kW 1
7
GHD25-2-07
Slotted cheese head screws M6X20 4
8
GHD25-2-08
Hose clamp 1
9
GHD25-2-09
Hose Ø10X1500 1
10
GHD25-2-10
Cooling pipe L=400 1
11
GHD25-2-11
Ball valve 1
12
GHD25-2-12
Tee 1
13
GHD25-2-13
Pipe joint 1
14
GHD25-2-14
Adjusting bracket 1
15
GHD25-2-15
Screw 1
16
GHD25-2-16
Hexagon socket head cap screws M6X14 2
17
GHD25-2-17
Supporting 1
18
GHD25-2-18 Column 1
19
GHD25-2-19 Screw M12X40 4
20
GHD25-2-20 Electrical box door 1
21
GHD25-2-21 Screw M4X12 1
22
GHD25-2-22 Rack 1
23
GHD25-2-23 Sleeve with steel ball 1
24
GHD25-2-24 Baffle ring 1
25
GHD25-2-25
Cover
1
26
GHD25-2-26 Screw M6X16 3
27
GHD25-2-27 Elbow pipe with shaft ring 1
Part List for GHD-25 DRILL PRESS
