27
58 ....... 5782881 ........................Flange Nut...........................................................M5 .......................... 12
59 ....... 5783581 ........................Hex Nut ...............................................................M8 ............................ 5
60 ....... 5625361 ........................Hex Nut ...............................................................M12 .......................... 1
61 ....... 5783071 ........................Hex Nut ...............................................................M16 .......................... 1
62 ....... 5782621 ........................Square Nut ............................................................................................ 1
63 ....... 5782581 ........................Wing Nut .............................................................M8 ............................ 1
64 ....... 5783461 ........................Roll Pin ................................................................3x8 ........................... 1
65 ....... 5782681 ........................Retaining Ring .....................................................R35 .......................... 2
67 ....... 5783091 ........................Flat Head Screw ..................................................M5x10 ...................... 4
68 ....... 5625121 ........................Hex Cap Screw ...................................................M6x10 ...................... 2
69 ....... TS-1482021...................Hex Cap Screw ...................................................M6x12 ...................... 6
70 ....... TS-1490071...................Hex Cap Screw ...................................................M6x16 ...................... 1
72 ....... 5782761 ........................Pan Head Screw .................................................M5x8 ........................ 1
73 ....... 5783141 ........................Hex Cap Bolt (Left Hand) ..................................... M8x20 ...................... 1
74 ....... TS-1482061...................Hex Cap Screw ...................................................M6x30 ...................... 2
75 ....... TS-1490071...................Hex Cap Bolt .......................................................M8x40 ...................... 4
76 ....... 5783551 ........................Hex Cap Screw ...................................................M8x80 ...................... 1
77 ....... TS-1491081...................Hex Cap Bolt .......................................................M10x50 .................... 2
78 ....... 5783051 ........................Hex Cap Bolt .......................................................M16x55 .................... 1
79 ....... 5782641 ........................Pan Head Screw .................................................M5x6 ........................ 2
80 ....... 5782871 ........................Pan Head Screw .................................................M5x8 ...................... 12
81 ....... 5782961 ........................Pan Head Screw .................................................M5x25 ...................... 5
82 ....... 5783131 ........................Pan Head Screw .................................................M6x8 ........................ 4
83 ....... 5783331 ....................... Set Screw............................................................M6x10 ...................... 7
84 ....... 5783361 ........................ Micro Adjustment Screw ................................................ M8x40 ...................... 2
85 ....... 5783271 ........................Set Screw ...........................................................M10x10 .................... 1
86 ....... 5782851 ........................Self Tapping Screw ..............................................M3.5x12 ................... 2
87 ....... 5782941 ........................Self Tapping Screw ..............................................M4x8 ........................ 2
88 ....... TS-1550041...................Flat Washer ........................................................M6 ............................ 2
89 ....... TS-1550041...................Flat Washer ........................................................M6 ............................ 1
90 ....... 5783231 ........................Flat Washer ........................................................ M8 ............................ 8
91 ....... 5783151 ........................Flat Washer .......................................................................................... 1
92 ....... 5783061 ........................Flat Washer ........................................................ M16 .......................... 2
93 ....... 5511752 ........................Lock Washer .......................................................M8 ............................ 8
94 ....... 5511752 ........................Lock Washer .......................................................M8 ............................ 2
97 ....... J-5782931 .....................Switch Bracket ...................................................................................... 1
98 ....... TS-1482021...................Hex Cap Screw ...................................................M6x12 ...................... 1
99 ....... 5782951 ........................Switch .................................................................1Ph .......................... 1
........... 5784694 ........................Switch .................................................................3 Ph ......................... 1
100...... 5782981 ........................Power Cord .........................................................115/230V, 1Ph .......... 1
........... 5513899 ........................Power Cord .........................................................230/460V, 3Ph.......... 1
100...... 5782991 ........................Power Cord (switch to motor) ..............................115/230V, 1Ph.......... 1
........... 5513900 ........................Power Cord (switch to motor) ..............................230/460V, 3Ph.......... 1
102...... 5782971 ........................Strain Relief .........................................................6W3-4R .................... 2
103...... 5783021 ........................Wire Clip ...............................................................................................1
105...... 5782881 ........................Flange Nut...........................................................M5 ............................ 4
106...... 5783431 ........................Flat Washer ........................................................M6x13x1 .................. 1
107...... TS-0720051...................Lock Washer, External Tooth ..............................#10 ........................... 4
112 ...... 5783671 ........................Spacing Sleeve ...................................................................................... 1
113 ...... 5783641 ........................Adjusting Block ..................................................................................... 1
114 ...... 5783651 ........................Guide Plate ........................................................................................... 1
115 ...... 5783731 ........................Adjusting Bar......................................................................................... 1
116 ...... 5783711 ........................Adjusting Bar......................................................................................... 1
Parts List – Saw Head – Models J-8201K, J-8203K, J-8201VS, and J-8203VS
In No. Part No. Description Size Qty.
