Jet JDP-15B Operating Instructions And Parts Manual

5.0 Specifications
Model number ....................................................................... JDP-15F ..................................................... JDP-15B
Stock number .......................................................................... 716250 ....................................................... 716200
Style ................................................................................. Floor mount .............................................. Bench mount
Motor and electricals:
Motor type………………………………………totally enclosed fan cooled, induction, capacitor start ..................
Horsepower .......................................................................... 3/4 HP ........................................................ 3/4 HP
Phase ..................................................................................... single .......................................................... single
Voltage ............................................................................. 115V only ................................................... 115V only
Cycle ....................................................................................... 60Hz ........................................................... 60Hz
Listed FLA (full load amps) ..................................................... 9.0 A ........................................................... 9.0 A
Starting amps ........................................................................... 18 A ............................................................ 18 A
Running amps (no load) ............................................................ 3 A .............................................................. 3 A
Start capacitor ..................................................... 150MFD, 125VAC ...................................... 150MFD, 125VAC
Run capacitor ........................................................... 40μF, 250VAC ........................................... 40μF, 250VAC
Power transfer ............................................................ 2 poly v-belts .............................................. 2 poly v-belts
On/off switch .................... push button with safety key, paddle stop ... push button with safety key, paddle stop
Motor speed .................................................................... 1720 RPM .................................................. 1720 RPM
Power cord .................................................. 16 AWG, 6 ft. (183 cm) .............................. 16 AWG, 6 ft. (183 cm)
Power plug installed .................................... 115V, 15A with ground ............................... 115V, 15A with ground
Recommended circuit size
1
.................................................... 15 A ............................................................ 15 A
Sound emission
2
.............................. 75dB at 39” (1m) without load .................... 75dB at 39” (1m) without load
Laser system ....................................................................... Class II ...................................................... Class II
Head and Capacities:
Swing
3
........................................................................ 15” (387mm) .............................................. 15” (387mm)
Chuck style and shank capacity ....................... keyed, 5/8” (16mm) .................................... keyed, 5/8” (16mm)
Chuck arbor taper ....................................................... JT-3 to MT-2 .............................................. JT-3 to MT-2
Spindle taper ........................................................................... MT-2 ........................................................... MT-2
Spindle travel, maximum ......................................... 3-1/8” (80 mm) ........................................... 3-1/8” (80 mm)
Spindle travel per one revolution of handle ............. 3-1/8” (80 mm) ........................................... 3-1/8” (80 mm)
Quill diameter ........................................................... 1-7/8” (47 mm) ........................................... 1-7/8” (47 mm)
Number of spindle speeds ........................................................... 16 ............................................................... 16
Maximum no-load speed range ........................... 210 to 3500 RPM ....................................... 210 to 3500 RPM
Maximum spindle to table distance ...................... 30-5/8” (778 mm) ....................................... 18-1/2” (471 mm)
Maximum spindle to base distance .................... 46-1/2” (1180 mm) ....................................... 26-7/8” (683 mm)
Maximum chuck to table distance ........................ 26-5/8” (676 mm) ....................................... 14-1/2” (368 mm)
Maximum chuck to base distance ...................... 42-1/2” (1080 mm) ....................................... 22-7/8” (581 mm)
Work lamp ................................................. integrated, pivoting LED ............................. integrated, pivoting LED
Depth stop type .................................................................... internal ....................................................... internal
Ma
terials:
Head .................................................................................. cast iron ..................................................... cast iron
Table ...................................................... precision-ground cast iron .......................... precision-ground cast iron
Table insert .............................................................................. MDF ........................................................... MDF
Column .................................................................................... steel ........................................................... steel
Base ................................................................................... cast iron ..................................................... cast iron
Table:
Table size .................................. 12-1/2” L x 17” W (320 x 435 mm) ............. 12-1/2” L x 17” W (320 x 435 mm)
Table slots (4) .................................. 2-3/4”L x 5/8” W (70 x 15 mm) ................... 2-3/4”L x 5/8” W (70 x 15 mm)
Table T-slots (2) ................................ 1/2” W x 5/8” D (13 x 15 mm) ..................... 1/2” W x 5/8” D (13 x 15 mm)
Distance between T-slots (centers) ..................... 10-5/8” (270 mm) ....................................... 10-5/8” (270 mm)
Table tilt ................................................................. 45 deg. L and R ......................................... 45 deg. L and R
Table rotation around column ............................................ 360 deg. ..................................................... 360 deg.
Table elevating system .................................... worm gear with rack ................................... worm gear with rack
Table insert ......................................... 3-3/4” x 3-3/4” (95 x 95 mm) ...................... 3-3/4” x 3-3/4” (95 x 95 mm)
Recommended maximum weight on table .................. 66 lb. (30 kg) .............................................. 66 lb. (30 kg)
