Remove all loose clothing and confine
long hair.
Before operating the machine, remove
tie, rings, watches, other jewellery, and
roll up sleeves above the elbows.
Wear safety shoes; never wear leisure
shoes or sandals.
Always wear the approved working
outfit.
Do not wear gloves.
Wear goggles when working
Install the machine so that there is
sufficient space for safe operation and
workpiece handling.
Keep work area well lighted.
The machine is designed to operate in
closed rooms and must be placed
stable on firm and levelled table
surface.
Make sure that the power cord does
not impede work and cause people to
trip.
Keep the floor around the machine
clean and free of scrap material, oil
and grease.
Stay alert!
Give your work undivided attention.
Use common sense. Do not operate
the machine when you are tired.
Do not operate the machine under the
influence of drugs, alcohol or any
medication. Be aware that medication
can change your behaviour.
Never reach into the machine while it
is operating or running down.
Never leave a running machine
unattended. Before you leave the
workplace switch off the machine.
Keep children and visitors a safe
distance from the work area.
Do not operate the electric tool near
inflammable liquids or gases.
Observe the fire fighting and fire alert
options, for example the fire
extinguisher operation and place.
Do not use the machine in a dump
environment and do not expose it to
rain.
Wood dust is explosive and can also
represent a risk to health.
Dust form some tropical woods in
particular, and from hardwoods like
beach and oak, is classified as a
carcinogenic substance.
Always use a suitable dust collection
device
Before machining, remove any nails
and other foreign bodies from the
workpiece.
Make sure to guide and hold the chisel
with both hands safe and tight during
machining.
Work only with well sharpened tools.
Machine only stock which is chucked
securely on the machine, always
check before switching the machine
on.
Provide workpieces with centre holes
before clamping between centres.
Work large and unbalanced
workpieces at low spindle speed only.
Workpieces with cracks may not be
used.
Remove the chuck key or dowel pins
before turning the machine on.
Always close the belt cover.
Specifications regarding the maximum
or minimum size of the workpiece
must be observed.
Do not remove chips and workpiece
parts until the machine is at a
standstill.
Never stop work pieces with the hand
during run out.
Never take measurements on a
rotating workpiece.
Do not stand on the machine.
Connection and repair work on the
electrical installation may be carried
out by a qualified electrician only.
Have a damaged or worn power cord
replaced immediately.
Make all machine adjustments or
maintenance with the machine
unplugged from the power source.
3.3 Remaining hazards
When using the machine according to
regulations some remaining hazards
may still exist.
The rotating workpiece can cause
injury.
Workpieces that are inhomogeneous
or weak can explode when being
processed due to centrifugal force.
Only process selected woods without
defects.
Unbalanced workpieces can be
hazardous.
Injuries can occur when feeding
tooling, if tool supports are not
correctly adjusted or if turning tools
are blunt.
Risk of kickback. The tooling is caught
by the rotating workpiece and thrown
back to the operator.
Thrown workpieces and workpiece
parts can lead to injury.
Dust and noise can be health hazards.
Be sure to wear personal protection
gear such as safety goggles and dust
mask. Use a suitable dust collection
system.
The use of incorrect mains supply or a
damaged power cord can lead to
injuries caused by electricity.
4. Machine specifications
4.1 Technical data
Swing over bed 250mm
Centre distance 350mm
Number of mechanical speeds 3
Spindle speed range 1 500-1200rpm
Spindle speed range 2 1100-2600rpm
Spindle speed range 3 1700-3900rpm
Headstock spindle nose 1” x 8 TPI
Headstock spindle taper MT 2
Tailstock spindle taper MT 2
Tailstock hole diameter 9mm
Tailstock ram travel 50mm
Tool rest length 150mm
Overall (LxWxH) 630x200x360mm
Net weight 30 kg
Mains 230V ~1/N/PE 50Hz
Output power 0,37 kW (0,5HP) S1
Reference current 3 A
Extension cord (H07RN-F): 3x1,5²
Installation fuse protection 10A
4.2 Noise emission
Acoustic pressure level (EN 11202):
Idling 67,4 dB (A)
In operation 76,5 dB (A)
The specified values are emission
levels and are not necessarily to be
seen as safe operating levels.
As workplace conditions vary, this
information is intended to allow the
user to make a better estimation of the
hazards and risks involved only.
