7
Sanding Drum
Drum dimensions, L x Dia 22-1/4 x 5 in. (565 x 127mm) 25-1/4 x 5 in. (642 x 127mm)
Drum speed 1725 RPM
Abrasive installed 80 Grit
Drum elevation per one rotation of handwheel 1/16 in.
Depth stop
Stop nut elevation per one rotation 0.100 in.
Conveyor
Conveyor speed infinitely variable within 0 to 10 FPM (0-3 MPM)
Conveyor table dimensions
23 x 21-3/4 in.
(584 x 552.5 mm)
26 x 21-3/4 in.
(660.4 x 552.5 mm)
Conveyor height from floor
(on OPTIONAL stand)
Open stand 34 in. (864 mm)
Closed stand 33-3/4 in. (857 mm)
Dust collection
Dust port outside diameter 4 in. (100 mm)
Minimum extraction volume required 550 CFM (15.6 CMM)
Dimensions
Assembled dimensions, mounted to OPTIONAL
open or closed stand, LxWxH
42 x 24 x 52 in.
(107 x 61 x 132 cm)
45 x 24 x 52 in.
(114.3 x 61 x 132 cm)
Shipping carton, base machine
44-1/2 x 27-1/2 x 28-1/4 in.
(113 x 70 x 71.75 cm)
44-1/2 x 27-1/2 x 28-1/4 in.
(113 x 70 x 71.75 cm)
Shipping carton, open stand (OPTIONAL) LxWxH
38 x 20 x 4-1/2 in.
(96.5 x 50.8 x 11.4 cm)
44 x 20 x 4-1/2 in.
(112 x 50.8 x 11.4 cm)
Shipping carton, closed stand (OPTIONAL) LxWxH
40-9/16 x 19-11/16 x 30-
5/16 in. (103 x 50 x 77 cm)
Weights
Net weight, base machine only (approx.) 177 lbs. (80.5 kg) 183 lbs. (83 kg)
Shipping weight, base machine only (approx.) 244 lbs. (111 kg) 256 lbs. (116.5 kg)
1
Subject to local/national electrical codes.
2
The specified values are emission levels and are not necessarily to be seen as safe operating levels. As workplace
conditions vary, this information is intended to allow the user to make a better estimation of the hazards and risks
involved only.
3
Use of a carrier or backer board (not provided) is recommended for cuts 1/16” or less. See sect. 9.3.
L=length, W=width, H=height, Dia=diameter
The specifications in this manual were current at time of publication, but because of our policy of continuous
improvement, JET reserves the right to change specifications at any time and without prior notice, without
incurring obligations.
