IF NEEDED - SEEK HELP OF A THIRD PERSON
Check Box When This Step is Complete
Checking the seem of the acrylic and cabinet glass
Check Box When This Step is Complete
When the acrylic is aligned properly with the glass - the top should
drop smoothly into place creating a perfect seem.
DO NOT REST THE TOP SECTION ON THE ACRYLIC - IT
WILL BREAK
Check Box When This Step is Complete
Checking the overall appearance
After Section # 3 is installed on top of Section # 2 - step back and
check the alignment of the entire structure.
Lifting section # 3 into place - Cont.
Carefully guide the acrylic onto the cabinet glass while lowering the
unit into the mounting holes. Let the unit down naturally - do not
force it. If it will not go smoothly into place - pull it up and then try
again. A third person can help guide the acrylic into place or tell the
installers which way they need to orient the piece.
INSTALLATION INSTRUCTIONS
Jennison Entertainment Technologies Space Ballz Service Manual Page 19
