Jet SPACE BALLZ - Page 27

Check Box When This Step is Complete
Connecting Electrical Connectors
1) Pull the 5 Wires through the opening on the left from Section # 3
to Section # 4
Check Box When This Step is Complete
Step # 7-J
Connecting Upper Left Cabinet Wires - Section # 4
1) Connect the 10-Pin Molex connector to the round LED board on
your left in Section # 4.
Step # 7-H
Connecting Electrical Connectors
1) Locate the 5 Connectors in Section # 3. These are located on the
left side of the cabinet (Looking at the game front).
Check Box When This Step is Complete
Step # 7-I
INSTALLATION INSTRUCTIONS
1
Jennison Entertainment Technologies Space Ballz Service Manual Page 27
