Complete System Connection Diagram RXi

Table of Contents

Default Chapter3
- Table of Contents3
Introduction5
Quick Start Section for Rx Turbines with V10 Ecu8
- Identify Components8
Mounting the Turbine Support Equipment (Rx)9
Mounting the Turbine (Rx/Rxi)9
- Turbine Side View / Thrust Tube10
Inlet Protection10
Connections11
- Complete System Connection Diagram Rx11
- Complete System Connections Rx Photo12
- Fuel Connections Rx13
- Hopper Tank - Uat13
- Electrical Connection14
- Interconnections14
- Complete System Connection Diagram Rxi15
- System Connection Rxi Photo16
Power17
Ground Support Unit (Gsu)18
- Gsu Control Panel Descriptions18
- Gsu Switch Descriptions19
The Led I/O Board19
- Description of Leds on the Gsu and Led Board19
Jetcat V10 Ecu20
- Switching on the Ecu20
Single or Two Channel Operation21
- How to Set Your Ecu for Single Channel Operation21
Setup Failsafe Mode21
- Setting the Failsafe21
- Learn R/C". Teach the Ecu to the R/C System23
- Verify Failsafe Programing25
?Learn R/C”. TEACH the ECU to the R/C SYSTEM25
Preparing Fuel and Fuel System25
- Fueling on Board Tanks25
- Prime the Pump and System (Not Needed for the Rxi)26
Running the Turbine for the First Time26
- The Checklist26
- Before Running the Turbine26
- After Stopping the Turbine26
- Starting and Stopping the Turbine27
- After the Start Process Is Initiated, the Following Occurs27
- Automatic Cooling Process27
Gsu (Run Menu Default) Display Symbols28
- Initial Default Display Screen after Power up28
- After Power up - "Error Condition" Display Screen28
- Turbine Starting Display Screen30
- Turbine Running Display Screen30
Turbine Running States30
- Explanation of the Turbine States31
Troubleshooting33
- Most Frequent Errors. Cause and Remedy33
- Reason for an Unexpected Shut-Down34
Manual Advanced Section35
Jetcat Ecu Features Version 10.0035
- Smoker Valve36
Menu Structure40
- Menu Selections40
  - Selecting a Menu40
  - Change Values / Items40
- The Run Menu40
- The Min/Max Menu41
- The R/C Check Menu41
- The Info Menu42
- The Statistic-Menu43
- The Limits Menu43
Airspeed Sensor47
- Special Function53
  - Temperatur Adjustment53
  - Reset to Default Value54
