Overview of Pumps

Pumpe, Type

Engine

B2

P20 SE/SX

C4

P140RX/P180RX/P200RX

D8

-

E16

P300RX/P400RX

Smokerpumpe PRO

-

The Smokerpumpe PRO can’t be switched because it’s no Bus-

Pump, further it is impossible to set up the flow by GSU.

Proceed according the Smokepump PRO manual.
