Engine Running States
The JetCat engine progresses through several operating states, from ignition to the cool down process. The
transitions of these states are automatically controlled by the ECU and by user commands. The current value is always
displayed on the GSU screen in the STATE selection in the RUN menu. When the engine is starting, the GSU will also
display the current state on the bottom line of the display. Whenever the engine is in cooling mode or the starter is
tested with the Spool key, the top line of the GSU display will flash “! – Cooling - !”.
Explanation of the engine States
Table 1
Value Explanation
-OFF- AUX switch in the Off position and/or the throttle trim in the Off position. All LEDs are
off. Turbine is off (preventing starting).
Standby /
START
AUX switch positioned to the Start / Standby position, throttle trim at maximum and
throttle stick at idle. The LED chase sequence is started from green to red to yellow,
continuously. When throttle stick is advanced to the maximum position, the starter
motor engages to spin the rotor. When RPM reaches a pre-programmed value, the
starter motor’s voltage is removed and the engine is ready to ignite.
Pre Heat 1 The burner is pre-heated for 3-7 seconds (the starter motor is not running)
Pre Heat 2 The starter motor spools up the engine to it’s ignition. After another few seconds the ignition
of the engine is engaged by injecting kerosene into the Kerosene-Igniter. The pump and the
internal starting fuel solenoid will begin pulsing.
MainF
-
On
Main fu
el solenoid opens and kerosene is modulated into the engine.
AccelDly Delay while combustion chamber is preheating. Waiting for a rise in EGT.
Ker.Full Starting fuel solenoid closes and all the fuel is now directed to the main injectors. The red
Pump running LED turns on and will stay illuminated as long as the pump operates.
Stabil. Turbine successfully accelerates to the idle RPM, then automatically increases speed to about
30% higher RPM. When this speed is maintained consistently for at least one second, the
engine
will proceed to the next state (
Learn LO)
.
Learn LO In this state, the engine automatically decreases RPM to the idle speed.
As soon as idle speed is attained, with the throttle stick in the idle position, the engine will
proceed to the next state (
RUN (reg.)
).
Run (reg.)
Turbine in the normal running state; the throttle stick will regulate engine thrust.
During this operant condition, the green OK LED will illuminate, indicating that pilot has
control. (red LED is already illuminated)
RUN (regulated)
continues, until the
engine
is switched off.
Auto Off
The AUX switch placed in the Auto Off position.
Turbine automatically increases RPM if at idle and remains at that RPM for a few seconds,
before transition to the next state (
Slow Down)
.
Slow Down
During this state, the fuel shut-off valve is closed and the fuel pump is stopped.
The green OK LED blinks and the GSU displays !-Cooling-!, indicating Slow Down
This condition will continue, until all the following parameters are met:
 Turbine speed less than 800 RPM
 EGT is less than 100 degrees C.
 The AUX switch is moved to the Off position and throttle trim is moved to the minimum
position
