Jeti Duplex DC-24 - Page 105

computer radio control system
EN
Trainer Mode with two JETI DS/DC Radios
1. Make sure that the instructor’s transmitter is bound to the
aircraft in the “Default” wireless mode and that all flying
surfaces are functioning properly.
2. Change the instructor’s transmitter wireless mode to
“Teacher” and authorize the secondary TX module to bind
with the student’s transmitter.
3. Switch ON the student’s transmitter, change its wireless mode
to “Student” and allow the instructor’s transmitter to bind
properly. Verify that all of the aircraft’s surfaces are correctly
controlled by the student’s transmitter. If they are not correct,
make the necessary changes in the student’s transmitter.
Trainer Mode for JETI DS/DC as the Instructor Radio
Other brands of transmitters can be used by the student with a JETI
Duplex EX 2.4GHz radio system by using a special wireless “Trainer”
communication module by JETI.
1. Make sure that the instructor’s transmitter is bound to the
aircraft in the “Default” wireless mode and that all flying
surfaces are functioning properly.
Change the instructor’s transmitter wireless mode to“Teacher” 2.
and authorize the secondary TX module to bind with the
student’s transmitter.
Connect the wireless trainer module to the student Tx “Trainer 3.
Jack” (see Tx manual), then prepare the module for binding to
the instructor Tx by inserting the bind plug into the “Ext” port
(see the module guide).
Verify that all of the aircraft’s surfaces are correctly controlled by 4.
the student’s transmitter. If they are not correct, make the
necessary changes in the student’s transmitter.
Double Path Wireless Mode
a) Mode Selection.
b) Primary RF module bind control menu line
c) Secondary RF module bind control menu line
d) Optional signal loss alarm settings.
4. 4.
a
b
c
d
104
