Jetson Haze - Attaching the Seat

24
1.6 Attaching the Seat
1. OPEN THE SEAT CLAMP LEVER AND LOOSEN THE
KNOB TO WIDEN THE CLAMP.
2. SLIDE THE SEAT POST IN.
3. ENSURE THE SEAT POST REACHES THE MINIMUM
INSERTION LINE MARKED ON THE POST.
SEAT POST
MINIMUM INSERTION LINE
SEAT CLAMP KNOB
SEAT CLAMP LEVER
