3. LOOSEN AND REMOVE THE BOLT FASTENING THE BRAKE ARM TO THE BRAKE COVER PANEL BY TURNING IT
COUNTERCLOCKWISE WITH YOUR FINGERS OR THE SCREWDRIVER. IF NECESSARY, USE THE 8MM WRENCH TO HOLD THE
NUT ON THE BACK SIDE OF THE BRAKE ARM STEADY SO THAT YOU CAN MORE EASILY TWIST THE BOLT.
4. SET THE BOLT, WASHER, AND NUT ASIDE.
8 MM
WRENCH
NUT
WASHER
BOLT
SCREWDRIVER
BRAKE MECHANISM
FRONT FORK
BRAKE COVER PANEL
BRAKE ARM
